20mm Stainless Steel Eye Bolt Similar to DIN 580 - AISI 316
In stock
SKU: SSDINEB20
| D1 | 40mm |
| D2 | 72mm |
| D3 | 40mm |
| E | 12mm |
| B | 30mm |
| H | 35mm |
| D | M20 |
| K | 20mm |
| Breaking Load | 7000kgs |
| Product Weight | 0.45kgs |
| Material | AISI 316 - A4 Grade |
| Finish | Polished |
- 20mm stainless steel eye bolt
- AISI 316 - A4 grade steel lifting bolt with highly polished
- BREAKING LOAD RATED, this rating outlines the product performance, it should not be used for lifting or safety critical applications, this product can not be certified.
- WLL Load rated versions are available here - LOAD RATED WLL FORGED EYE BOLTS
£11.76
£9.80
- Buy 50 for £11.28 £9.40 each
- Buy 100 for £11.04 £9.20 each
