3mm Stainless Steel Eye Bolt Similar to DIN 580 - AISI 316
In stock
SKU: SSDINEB03
| D1 | 7mm |
| D2 | 13mm |
| D3 | 7.8mm |
| E | 3mm |
| B | 8.5mm |
| H | 8mm |
| D | M3 |
| K | 2.6mm |
| Breaking Load | 40kgs |
| Product Weight | 0.04kgs |
| Material | AISI 316 - A4 Grade |
| Finish | Polished |
GS Products supply reliable AISI 316 - A4 grade stainless steel 3mm mini eye bolts with a polished finish.
- Most commonly used to attach ropes or cables to a fixed structure
- Similar to DIN 580 specification
- 3mm diameter thread - our smallest eye bolt
- BREAKING LOAD RATED, this rating outlines the product performance, it should not be used for lifting or safety critical applications, this product can not be certified.
- WLL Load rated versions are available here - LOAD RATED WLL FORGED EYE BOLTS
£1.19
£0.99
- Buy 50 for £1.16 £0.97 each
- Buy 100 for £1.13 £0.94 each
