5mm Stainless Steel Eye Bolt Similar to DIN 580- AISI 316
In stock
SKU: SSDINEB05
| D1 | 15mm |
| D2 | 25mm |
| D3 | 15mm |
| E | 5mm |
| B | 11mm |
| H | 12mm |
| D | M5 |
| K | 5mm |
| Breaking Load | 320kgs |
| Product Weight | 0.04kgs |
| Material | AISI 316 - A4 Grade |
| Finish | Polished |
GS Products supply reliable AISI 316 - A4 grade stainless steel 5mm eye bolts with a polished finish.
- Excellent option for an array of different purposes
- Most commonly used to attach ropes or cables to a fixed structure
- Similar to DIN 580 specification
- BREAKING LOAD RATED, this rating outlines the product performance, it should not be used for lifting or safety critical applications, this product can not be certified.
- WLL Load rated versions are available here - LOAD RATED WLL FORGED EYE BOLTS
£0.98
£0.82
- Buy 50 for £0.97 £0.81 each
- Buy 100 for £0.96 £0.80 each
