7x19 Stainless Steel Wire Rope - Custom Lengths

This A4 - AISI 316 marine grade stainless steel wire rope is an extra flexible 7x19 construction

It’s ideal for use where high flexibility high flexibility and fatigue performance are important

The steel wire rope consists of 19 strands of individual cable, twisted into 7 larger cables which make up the steel rope

Available in a range of sizesfrom 1.5mm-16mm diameter

PRICED PER METER - Simply add your required steel wire rope meterage into the quantity box and we will supply it in a single reeled length

In stock
Grouped product items
Product Diameter (mm) Min Breaking Load (Kgs) Weight (Kgs/100mtrs) PRICE Qty
1.5mm 7x19 Stainless Steel Wire Rope - Per Meter 1.5 130 1.01
£0.37 £0.31
2mm 7x19 Stainless Steel Wire Rope - Per Meter 2 232 1.52
£0.42 £0.35
2.5mm 7x19 Stainless Steel Wire Rope - Per Meter 2.5 362 2.38
£0.55 £0.46
3mm 7x19 Stainless Steel Wire Rope - Per Meter 3 521 3.43
£0.71 £0.59
4mm 7x19 Stainless Steel Wire Rope - Per Meter 4 927 6.10
£0.95 £0.79
5mm 7x19 Stainless Steel Wire Rope - Per Meter 5 1448 9.61
£1.87 £1.56
6mm 7x19 Stainless Steel Wire Rope - Per Meter 6 2086 13.80
£2.48 £2.07
7mm 7x19 Stainless Steel Wire Rope - Per Meter 7 3200 18.67
£3.59 £2.99
8mm 7x19 Stainless Steel Wire Rope - Per Meter 8 3708 24.38
£4.79 £3.99
10mm 7x19 Stainless Steel Wire Rope - Per Meter 10 5793 38.10
£5.99 £4.99
12mm 7x19 Stainless Steel Wire Rope - Per Meter 12 8343 54.86
£8.02 £6.68
14mm 7x19 Stainless Steel Wire Rope - Per Meter 14 11355 74.68
£20.39 £16.99
16mm 7x19 Stainless Steel Wire Rope - Per Meter 16 14831 97.54
£22.79 £18.99
Show Price without VAT


Questions and Answers

Q. How do i order 120 meters?

If you require 120 meters then simply add '120' into the quantity box and we will supply it in on a 120 meter reel

Q: What does 7x19 mean?

It means that the wire is made of 7 main strands and each of those 7 strands is made up of 19 smaller strands

Q. Can i bend this 7x19 wire back and make loops?

Yes, this is the perfect wire rope as it is very flexible and perfect to make wire rope eye lets

Q: What is the diameter of 2mm 7x19 stainless wire rope?

The diameter is 2mm overall

Q: Is this wire rope suitable to use with pulleys?

Yes, as it is flexible it is perfect to use over pulleys

Q. What is the lead time if i order this wire today

Usually 1-2 working days

Q: Will this wire be reeled onto a wooden reel?

Usually yes, but this depends on how much wire rope you order, if it is a small amount (eg. 10 meters) it will not be on a reel, also smaller diameters maybe supplied on smaller cardboard reel which have a steel center

Q: What do i do if i require specific cut lengths?

Simply leave us a note on checkout and we will do this for you within reason  (see below)
