5.3ton WLL Weld On Lashing D Ring Grade 80
In stock
SKU: EBHW031
Grade 80 Weld On Lashing Link High Tensile Steel
These lashing d rings conform to EN12640 and have a 2:1 safety factor, they are WLL and CE marked. The ring pivots 180 degrees
To achieve full load these rings must be welded in accordance to DIN5817 resp 15429 by a qualified welder to EN287-1
Drawing Sizes
| A | 55mm |
| B | 115mm |
| D | 23mm |
| H | 60mm |
| M | 45mm |
| WLL | 5.30ton |
£16.79
£13.99
