Stainless Steel Wire Rope Cone Head Terminal

Stainless steel swaje jaw terminals

Made with A4 AISI-316 stainless steel

To fit onto wire rope they need to be hydraulically swaged on

Includes a removable clevis pin on the terminal which is held captive by a split ring

Sizes available range from 2mm-12mm diameters

In stock

Grouped product items
Product	A (mm)	L (mm)	D (mm)	D1 (mm)	L1 (mm)	Suit Wire Diameter (mm)	PRICE
3mm Cone Head	27	35	8	6	2	3	£0.98 £0.82
4mm Cone Head	35	43	9.5	7.4	2	4	£1.10 £0.92
5mm Cone Head	40	50	12.5	8.5	3	5	£1.42 £1.18
6mm Cone Head	50	65	16	12.5	2.5	6	£2.57 £2.14

Show Price without VAT
